TY30D Max Pull 35kN Stringing Equipment Hydraulic Puller Deutz Air Cooled Cooling System

TY30D Max Pull 35kN Stringing Equipment Hydraulic Puller Deutz Air Cooled Cooling System

Product Details:

  • Product Type Stringing Equipement
  • Weight 2000 Kilograms (kg)
  • Color Orange
  • Height 2000 Millimeter (mm)
  • Size 3200*1600*2000mm
  • Width 1600 Millimeter (mm)
  • Length 3200 Millimeter (mm)
  • Supply Ability : 100 Set Per Month
32598 USD ($)/Set
X

Price And Quantity

  • 32598 USD ($)/Set
  • 1 Set

Product Specifications

  • 1year
  • Stringing Equipement
  • 2000 Kilograms (kg)
  • Orange
  • 2000 Millimeter (mm)
  • 3200*1600*2000mm
  • Other
  • Other
  • 1600 Millimeter (mm)
  • Hydraulic
  • 3200 Millimeter (mm)

Trade Information

  • Shanghai, Tianjin, Ningbo, Guangzhou
  • Western Union, Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C)
  • 100 Set Per Month
  • 15-30 Days
  • Container
  • South America, Asia
  • All India
  • ISO9001, CE

Product Description

TY30D Hydraulic Puller

Together with tension machine, this model allows for the tension stringing of 220kV lines in mountainous and hilly areas and can be used for the traction stringing of OPGW or ADSS cable in various terrains.

Characteristics

  • Bull-wheel diameter:300mm
  • Groove number: 7
  • Max rope diameter: 13mm
  • Applicable to the max connector diameter: 40mm
  • Max diameter of rope reel: 1400mm
  • Total weight: 2000kg
  • Overall dimension (length*width*height): 3200*1600*2000mm
  • Structure style: single bridge trailer



Performance

  • Max pull: 35kN
  • Rated pull: 30kN
  • Corresponding Pulling Speed: 2.5km/h
  • Max Corresponding Pulling Speed: 5km/h
  • Corresponding Pulling Force: 15kN



Engine

  • Diesel: 56kw(73hp)
  • Cooling system: air cooled
  • Electrical system: 24V



Main configuration

  • Engine: Cummins
  • hydraulic pump: German Rexroth
  • Main motor: German Rexroth
  • speed reducer: German Rexroth
  • Tail bracket hoisting motor: American Eton
  • Hydraulic meter: German WIKA
  • Operating handle: German Rexroth



Hydraulic Transmission

Closed hydraulic circuit for step less speed variation in both rotating directions. This machine is provided with a pull pro-setting system that maintains the pre-set pulling value (also when the speed is reduced to "0") by automatically adjusting the operation speed according to the friction and unexpected loads which may occur.

 Configuration

  • Hydraulic dynamometer with set-point and automatic control of maximum pull
  • Hydraulic oil cooling system
  • Control instruments for hydraulic system and diesel engine
  • On board reel winder with automatic level wind, suitable for standard reel mod. 1400 and 1600
  • Hydraulic front stabilizer
  • Grounding connection point



Additional Devices

  • Lighting system for the trailer
  • Hydraulic rope clamp for reel change
  • Swivel guide rope roller
  • Trailer for towing at max speed of 30 km/h
  • Extra shaft
  • Digital speed and meter counter (extra charge)
