Pulling Grip Come Along Clamps

Product Details:

Product Type Transmission Line Tools
Material High Tensile Steel Wire
Welding Standard Spot Welded at Critical Points
Capacity Up to 5 Ton
Application Used for Tensioning, Pulling and Laying Cables or Conductors
Galvanization Standard ASTM A153 / ISO 1461
Out Coating Electro Galvanized / Hot Dip Galvanized
Share Your Product:

54 USD ($)/Set

Get a Price/Quote

Request To Call Back Send Inquiry

Pulling Grip Come Along Clamps Price And Quantity

Price 54 USD ($)/Set
Minimum Order Quantity 100 Set

Cable Diameter Range 8mm - 50mm
Handle Type Ergonomic Rubber Coated
Mesh Type Double/Single Weave Open Mesh
Jaw Opening 25mm to 85mm (Depends on Model)
Corrosion Resistance Yes
Temperature Range -20C to 70C
Operating Method Manual, No Power Required
Weight 1.5 kg - 6 kg (Model Dependent)
Safety Factor Above 5:1
Reusable Yes, Multiple Times

Pulling Grip Come Along Clamps Product Specifications

Color Metallic Silver
Material High Tensile Steel Wire
Shape Grip Clamps - Open Mesh
Out Coating Electro Galvanized / Hot Dip Galvanized
Application Used for Tensioning, Pulling and Laying Cables or Conductors
Design Braided Open Mesh with Flexible Eye
Capacity Up to 5 Ton
Standard IS 16173 / Custom Industrial Specification
Galvanization Standard ASTM A153 / ISO 1461
Welding Standard Spot Welded at Critical Points
Product Type Transmission Line Tools
Surface Treatment Galvanized
Height Variable as per Model
Thickness 5 mm - 15 mm (Depending on Model)

Cable Diameter Range 8mm - 50mm
Handle Type Ergonomic Rubber Coated
Mesh Type Double/Single Weave Open Mesh
Jaw Opening 25mm to 85mm (Depends on Model)
Corrosion Resistance Yes
Temperature Range -20C to 70C
Operating Method Manual, No Power Required
Weight 1.5 kg - 6 kg (Model Dependent)
Safety Factor Above 5:1
Reusable Yes, Multiple Times

Pulling Grip Come Along Clamps Trade Information

FOB Port Shanghai,Tianjin,Ningbo
Payment Terms Telegraphic Transfer (T/T), Letter of Credit (L/C)
Supply Ability 50000 Set Per Month
Delivery Time 30 Days
Packaging Details container
Main Export Market(s) Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market All India
Certifications iso9001

Product Description

TYSK Self Gripping Clamps

The self-gripping clamps can be use to anchor and to string conductor. The body is made of high strength hot forged steel or Aluminum, in order to minimize the ratio between weight and working load.

G is usd to say that it is equipped with protection hook device, its test intensity up to 3 times, and not hurt conductor.

Model	Conductor size (mm2)	Rated load (kN)	Max. opening (mm)	Weight (kg)
SKL-7	25-70	7	14	1.0
SKL-15	95-120	15	18	1.4
SKL-25	150-240	25	24	3.0
SKL-40	300-400	40	32	4.0
SKL-50	500-630	50	36	6.6
SKL-50B	630	50	36	6.6
SKL-40G	400	40	32	4.3
SKL-50GA	500	50	34	7.0
SKL-50GB	630	50	36	7.3
SKL-60G	720	60	38	9.2
SKL-70	900	70	42	14
SKL-70G	900	70	42	14
SKL-80G	1000	80	45	18
SKL-80GA	1200	80	48	18

Robust Construction and Versatile Design

These clamps are made from high-tensile steel wire and spot welded at critical points to deliver strength and reliability. The double or single open mesh weave design allows for a snug grip on a wide range of cable diameters, suitable for diverse pulling and tensioning jobs in industrial settings. With variable height and thickness, along with metallic silver galvanized finish, the clamps are engineered for durability and tailored to user requirements.

Exceptional Safety and Comfort Features

With a safety factor that surpasses 5:1, operators can trust these clamps to handle heavy-duty tasks safely, supporting loads up to 5 tons. The ergonomic, rubber-coated handle ensures a secure, comfortable grip, greatly reducing strain during repetitive manual operations. Reusability and proven corrosion resistance make them an economical and practical choice for frequent use in harsh environments.

Easy Operation and Maintenance-Free Use

Meeting international standards such as IS 16173, these clamps are designed to be operated manually without electricity, making them convenient for job sites without power access. Galvanized to resist corrosion and requiring minimal maintenance, each clamp is a reliable, cost-effective tool for distributors, suppliers, and contractors across various industries.

FAQ's of Pulling Grip Come Along Clamps:

Q: How do I choose the correct Pulling Grip Come Along Clamp for my cable diameter?

A: Select a clamp model that matches your cable diameter range, which can span from 8mm up to 50mm. Ensure the jaw opening supports your specific cable or conductor and confirm the required mesh type-either single or double weave-for optimal grip.

Q: What applications are these grip clamps best suited for?

A: These clamps are ideal for tensioning, pulling, and laying cables or conductors in electrical installations, utility projects, and construction sites. Their robust design and high load capacity make them well suited for both temporary and permanent cable installation.

Q: When should I use a double weave versus a single weave open mesh?

A: Double weave open mesh offers extra grip and holding strength, making it suitable for longer pulls or heavier cables. Single weave is recommended for lighter cables or shorter pulls. Choose based on cable size, length of pull, and required holding strength.

Q: Where can these clamps be used given their temperature range and corrosion resistance?

A: With a temperature tolerance of -20C to 70C and excellent corrosion resistance per ASTM A153/ISO 1461, these clamps can be used indoors or outdoors, including harsh industrial and marine environments where exposure to moisture or temperature variations is common.

Q: How do I ensure safety while operating these clamps?

A: Always ensure the selected model's capacity is not exceeded-these clamps support up to 5 tons. Confirm the clamp is correctly installed, the cable fits the specified diameter, and the mesh is properly engaged. The 5:1 safety factor provides an additional level of assurance during use.

Q: What are the benefits of the ergonomic rubber-coated handle?

A: The ergonomic handle provides a comfortable, non-slip grip even during extended manual operations, reducing hand fatigue and enhancing operator control and safety during cable pulling.

Q: Can these come along clamps be reused multiple times?

A: Yes, these clamps are designed for repeat use. Their durable materials and galvanized coating ensure longevity and consistent performance over multiple projects, offering excellent long-term value for regular users.
