XD-100A Hydraulic Ratchet Cable Cutter Hand Armoured Cable Cutter
Product Details:
- Product Type Ratchet Cable Cutter
- Material High-Strength Alloy Steel
- Capacity Up to 100mm (Copper/Aluminum Armoured Cable)
- Application Cutting Armoured Copper and Aluminum Cables
- Out Coating Painted
- Standard Industry Standard
- Shape Ergonomic Hand Tool
20.00 - 190.00 USD ($)/Piece
X
XD-100A Hydraulic Ratchet Cable Cutter Hand Armoured Cable Cutter Price And Quantity
- 50 Piece
- 20.00 - 190.00 USD ($)/Piece
- Portable Hand Tool
- up to Ø 100 mm²
- Silent Operation
- Manual Hydraulic
- Ratchet Action
- Safety Lock Equipped
- Power Cable, Telecom Cable Armoured Cable Cutting
- 6.8 kg
- High Hardened Alloy Steel
- XD-100A
- Comfort Grip PVC-Coated
- 55-60 HRC
XD-100A Hydraulic Ratchet Cable Cutter Hand Armoured Cable Cutter Product Specifications
- Painted
- Industry Standard
- Manual (No Voltage)
- Ratchet Cable Cutter
- Ratchet Hydraulic Mechanism
- High-Strength Alloy Steel
- Heavy Duty Build
- 46 cm
- Red and Black
- Ergonomic Hand Tool
- Up to 100mm (Copper/Aluminum Armoured Cable)
- Cutting Armoured Copper and Aluminum Cables
- Corrosion Resistant
- Portable Hand Tool
- up to Ø 100 mm²
- Silent Operation
- Manual Hydraulic
- Ratchet Action
- Safety Lock Equipped
- Power Cable, Telecom Cable Armoured Cable Cutting
- 6.8 kg
- High Hardened Alloy Steel
- XD-100A
- Comfort Grip PVC-Coated
- 55-60 HRC
XD-100A Hydraulic Ratchet Cable Cutter Hand Armoured Cable Cutter Trade Information
- Shanghai, Tianjin, Guangzhou, Ningbo
- 5000 Piece Per Month
- 10-35 Days
- Box
- Africa, Western Europe, Eastern Europe, Australia, South America, North America, Middle East, Central America, Asia
- All India
- ISO9001
Product Description
General features
Ratchet cable cutter with handiness & save labour.
The blades are manufactured from high strength special steel, heat treated to ensure a long service life.
The blades can sharpen or replace
The handle can be extended as your requirement
| Model | TYXD-40 | TYXD-520A | TYXD-J-40 | TYXD-75A | TYXD-100A | TYXD130A | TYJ-40B | TYJ-30 | TYJ-40 |
| Cutting range | Cutting off Cu/Al cable smaller than 300mm2 | Cutting off Cu/Al cable smaller than 600mm2 | Cutting off ACSR cable smaller than 800mm2 | Cutting off ACSR cable smaller than 800mm2 |
Al/Cu cable max.100 mm |
Al/Cu cable max.130 mm |
Cutting off Cu/Al cable smaller than 240mm2 | Cutting off steel wire ropes smaller than 100mm2 and ACSR small than 630mm2 | Cutting off Cu/Al armored cable smaller than 300mm2 and 1000pairs of communication cables |
| ACSR 32mm | Strands steel wire smaller than 120mm2 | Strands steel wire smaller than 120mm2 |
Armored cable max.100 mm |
Armored cable max.130 mm |
|||||
| Bolt 10mm | |||||||||
| Steel wire ropes 8-16 | |||||||||
| Length | 325-425mm | 350-450mm | 350-450mm | 550-730mm | 600-900mm | ||||
| Weight | 2.0kg | 1.9kg | 2.6kg | 2.6kg | 6.8kg | 7.0kg | 0.65kg | 3.5kg | 1kg |
| Package | Plastic case | Fabric bag | Fabric bag | Fabric bag | Fabric bag | Steel case | Fabric bag | Fabric bag | Fabric bag |
| Size |
240*40 *50mm |
33*15 *5.5cm |
38*17 *16cm |
38*17 *16cm |
55*27 *6.5cm |
60*31.5 *9.5cm |
350(510)*120 *45mm |
400(580)*160 *60mm |
330*120 *35mm |
Superior Cutting Performance
The XD-100A's high-hardened alloy steel blade ensures clean and swift cuts, even through tough armored cables. The ratchet hydraulic mechanism amplifies manual force, requiring less effort and delivering consistent, high-quality results every time.
Designed for Comfort and Safety
Equipped with PVC-coated handles, an ergonomic hand tool shape, and a dedicated safety lock mechanism, this cutter offers secure grip and safe handling. Its silent, shock-reduced operation also makes it suitable for noise-sensitive environments.
Portability and Versatility
Weighing only 6.8 kg and featuring a portable design, the XD-100A can be easily transported to various worksites. It is highly recommended for cutting power cables, telecom cables, and armored copper or aluminum cables, making it a versatile choice for diverse applications.
FAQ's of XD-100A Hydraulic Ratchet Cable Cutter Hand Armoured Cable Cutter:
Q: How does the XD-100A Hydraulic Ratchet Cable Cutter operate?
A: The XD-100A is manually operated using a hydraulic ratchet mechanism. This design allows for progressive cutting action with less physical effort, enabling users to handle thick armored cables efficiently without the need for electrical power.Q: What types of cables can the XD-100A cut?
A: This tool is specifically built to cut copper and aluminum armored cables up to 100mm2. It is suitable for both power and telecom cable applications, ensuring versatility across various electrical and communication installations.Q: When should I use the safety lock feature?
A: The safety lock should be engaged whenever the cutter is not in use or during transport. This prevents accidental opening or injury, ensuring both tool and user safety at all times.Q: Where can this hydraulic cable cutter be effectively used?
A: The XD-100A is designed for use in a wide range of environments, such as electrical substations, construction sites, telecom installations, and workshops. Its portable construction makes it ideal for fieldwork and on-site maintenance jobs.Q: What is the maintenance process for the XD-100A cable cutter?
A: To maintain optimal performance, clean the cutting blade after each use, check regularly for signs of wear or damage, and apply light lubrication to moving parts. Store the tool in a dry place with the safety lock engaged to prolong its life.Q: What are the benefits of using a manual hydraulic ratchet over standard hand cutters?
A: The hydraulic ratchet system multiplies manual force and reduces user fatigue. It provides smoother and more consistent cuts, particularly for thicker, armored cables, while maintaining silent operation, making it superior for demanding tasks.Tell us about your requirement
