TY2x40 Stringing Equipment Hydraulic Tensioner With Cummins Engine

TY2x40 Stringing Equipment Hydraulic Tensioner With Cummins Engine

Product Details:

  • Usage Transmission Line COnstruction
  • Weight 7800 Kilograms (kg)
  • Size 4900X2310X2900
  • Product Type Stringing Equipment Hydraulic Tensioner
  • Color Red
  • Body Material Steel
  • Type Other
  • Supply Ability : 50 Set Per Month
60100 USD ($)/Set
X

Price And Quantity

  • 60100 USD ($)/Set
  • 1 Set

Product Specifications

  • 4900X2310X2900
  • Hydraulic
  • Other
  • 7800 Kilograms (kg)
  • Steel
  • Transmission Line COnstruction
  • Red
  • Stringing Equipment Hydraulic Tensioner
  • 1year

Trade Information

  • Shanghai, Tianjin, Guangzhou, Ningbo
  • Telegraphic Transfer (T/T), Letter of Credit (L/C)
  • 50 Set Per Month
  • 10-35 Days
  • Container
  • Asia
  • All India
  • ISO9001 CE

Product Description

Purposes and Characteristics

This tension machine is a kind of large and high efficiency power construction machinery; it has high allocation of overall performance, ample power reserve, high delivery speed and wide use. It’s mainly used for delivery of all kinds of wire, optical cable and traction rope. It could meet tension delivery of wires like double Spacer LGJ-630 or below in mountain or upland, optical cables like OPGW or AESS in all kinds of terrain as well as tension delivery and counter-stretching of wires like 500 KV traction rope in all kinds of terrain. Two machines could meet tension delivery of wires like Four Spacer LGJ-720 or below in plain.



Performance Parameter

Main technical performance



1. Tension condition

a. Deliver the two wires (or steel wires) at the same time:

Maximum discontinuous tension: 2×50KN

Maximum continuous tension: 2×40KN

Corresponding speed: 2.5Km/h

Maximum continuous payout speed: 5Km/h

Corresponding tension: 2X20KN



b. Deliver one wire (or steel wire) in two juxtaposed wheels

Maximum continuous tension: 80KN

Corresponding speed: 2.5Km/h

Maximum continuous payout speed: 5Km/h

Corresponding tension: 40KN



2. Traction condition

a. Deliver one wire or steel wire not in two juxtaposed wheels (single wheel traction)

Maximum traction force: 40KN

Corresponding speed: 1.5Km/h

Maximum continuous payout speed: 5Km/h

Corresponding tension: 20KN



b. Deliver one wire or steel wire in two juxtaposed wheels

Maximum tension: 80KN

Corresponding speed: 1.5Km/h

Maximum continuous payout speed: 5Km/h

Corresponding tension: 40KN



Structure Parameters

Diameter of tensile force wheel: 1800mm

Concave-groove numbers: 5

Maximum applicable diameter of wire: 40mm

Deadweight of the whole machine: 7800kg

Overall dimension (length, width, height): 4900X2310X2900

Slinging method: double point slinging



Engine

Model: Cummins 4BT3.9

Nominal speed: 2800r/min

Nominal power (1 hour): 77KW



Transmission System

With closed double-loop hydraulic transmission system and planet decelerator, tension wheel is driven by primary gear. With inversion, the magnitude of reverse traction force is led by exit pressure of pump. In tension condition, hydraulic motor rotation is driven by the tension wheel; the magnitude of tension is controlled by regulating the motor exit pressure.



Main pump:

Type: Hydraulic control bidirectional variable plunger pump(Germany Rexroth )

Model: A4VG71HD



Type: Two-way Quantitative Plunger Piston Motor (Germany Rexroth )

Model: A2FE63/61W



Speed reducer:

Type: planet Gear Decelerator

Model: 306L2 18.1

Reduction ratio: 18.1

Brake opening pressure: 1.8MPA



Electrical System

System voltage: 24V

Storage battery: 6-QA-110

Diesel engine starting: 24V electric starting
